AC7HP – Rytons Baffled Controllable LookRyt® AirCore®

General Details

AC7HP – Rytons Baffled Controllable LookRyt AirCore

  • Retro-fitted core ventilator for background room ventilation.
  • Allows the introduction of fresh outside air into the room to disperse moisture, odours and other airborne pollutants.
  • Tube contains a light and draught reducing system of baffles.
  • Unique draught reducing panel manually adjusted with an easy push/pull or tilt action allowing air to be controlled as required.
  • Paint or wallpaper the panel to match room décor for a discreet appearance.
  • External water baffle prevents the transfer of water across the cavity.
  • External grille U.V. stabilised to slow down the effects of sunlight.
  • Position at high level (typically 1.7m above floor level) for all dwelling types and storey heights.
  • Patent No. GB 2523676.
  • PLEASE NOTE: This item is a plastic component and therefore not suitable for use within the external walls of high-rise buildings requiring non-combustible materials, i.e. those 18m high or more complying to Regulation 7(2) and Approved Document B, and those 11m high or more complying to 2.7 of Building (Scotland) technical handbook 2019.  For compliant alternatives, which includes our tailor-made design service, see Rytons A1 Fire-rated Ventilation Range.

Equivalent Area:

  • 6,500mm² (65cm²) per set (tested to BS EN 13141-1:2004 and independently verified by the BRE).

Size:

  • External grille: 166mm L x 160mm H.
  • Tube: 127mm (5″) Dia. x 358mm L (if required, a maximum 63mm may be cut from each end of the tube).
  • LookRyt panel: 172mm L x 172mm H.

Colours:

  • Terracotta: AC7HPTC.
  • Buff/Sand: AC7HPBS.
  • White: AC7HPWH.
  • LookRyt panel: Magnolia (may be painted or wallpapered to match décor).

Composition:

  • External grille: U.V. stabilised high impact polystyrene.
  • Tube: High impact polystyrene (contains recycled plastic). Softening point: 70ºC. Melting point: 120ºC.
  • LookRyt panel: High impact styrene. Melting point: 160-180ºC.

Handling Information:

  • Box quantity: 1 set.
  • Box size: 44cm W x 19cm H x 22.5cm D.
  • Box weight: 0.726kg.

Reference Material:

  • Equivalent area tested to BS EN 13141-1:2004 and independently verified by the BRE.
  • Also refer to: The Building Regulations 2000, Approved Document F,
  • The Building (Scotland) Regulations, Mandatory Standard 3.14,
  • The Building Regulations (Northern Ireland) 2000, Technical Booklet K,
  • British Standard BS 5250.
